Motherboard for Kobra S1/ S1C

1.Tools

S1.5 Allen Key*1

2. Disassembly steps:

Step 1: Disassemble the motherboard housing
1. The motherboard is located on the top right side of the machine.

2.Use an S1.5 Allen Key to unscrew the motherboard housing fixing screws.

Step 2: Remove the mainboard
1. Remove all wiring harnesses.

2.Use an S1.5 Allen Key to unscrew the motherboard fixing screws and remove the motherboard.

3. Installation steps:

Step 1: Install the motherboard
1. Use an S1.5 Allen Key to tighten the motherboard fixing screws.

2.Install all wiring harnesses to the main board terminals.

Step 2: Install the motherboard housing
Use an S1.5 Allen Key to tighten the motherboard housing fixing screws.
