ACMER P2 20W Laser Engraver
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
Zero assembly, easy to use. Fast speed. Laser power up to 20 Watts, with strong engraving and cutting performance. lt also integrates various safety measures such as flame detection and tilt protectior
The combination of 20 watts of output power and air assist providesun expected laser performance for cutting thick materials while dramatically reducing operating hours.
Plywood 25mm
Acrylic 20mm
MDF 8mm
The X and Y axes are equipped with industrial-grade linear guides, featuring superior structural design for enhanced stability and precision in engraving. Achieve a photo-quality experience with ultra-high pixel resolution.
Eye-catching yellow alarm indicator light gives you the quickest response to any malfunction or accident.
4 x6 Watts Powerful Diode Laser
Advanced laser synthesis compression technology generates a more power laser output by maintaining a fine beam size.
Unleash Your Laser Creativity to New Heights
- Rotary 360° Roller
- Time-lapse Camera
- Laser Enclosure Box
- Expansion Kit
ACMER Laser/ Lightburn /LaserGRBL /windows / Mac OS /Andriod
| Laser Output Power | 20000mw |
|---|---|
| Laser Type | Diode laser / Upgradeable 1064 laser |
| Machine Power | 120W |
| Laser Wavelength | 450±5nm |
| Power Supply | DC 24V/5A |
| Focal Length | 5mm |
| Engraving Accuracy | 0.01mm |
| Laser Module Design Life | 8000 hours |
| Maximum Engraving Speed | 30,000 mm/min |
| Working Area Size | 420*400mm |
| Assembly Method | Preassembled |
| Machine Size | 650*597*200mm |
| Machine Weight | 6.5kg |
| Movement structure | Industrial guide rail |
| Certification | FCC/CE/RoHS/FDA |
| Control Software | LightBurn/LaserGRBL/ACMER App(Android) / MKS(iOS) |
| Compatible Accessories |
1064 laser module, ACMER P2 Engraving Area Expansion Kit, Honeycomb Laser Bed , R10 Laser Enclosure Box , ACMER M2 Rotary Roller, ACMER C4 Air Assist |
| File Format Supported | JPG, SVG, PNG, BMP, G-code, CAD, AI, CDR, DWG, etc. |
| Safety Features |
Emergency stop button, Gyroscope detection(Tilt 15 degrees to automatically turn off the laser),Motherboard over-temperature protection,child safety lock, flame detector. |
Unbox and start using instantly!
lnexperienced beginners often encounter difficulties when
assembling a machine, but withACMER P2 Pre-Assembled
Edition, the machineis already assembled and rigorously
tested before leaving the factory, ensuring a superior user
experience.
Effortless Upgrade with Easy
Removable Laser Module
You can upgrade to a more powerful diode laser by replacing the
laser module, as well as upgrade to 33w or 1064nm infrared laser
for enhanced metal engraving and expand your engraving capabilities to include various materials like plastics.
Incredibly Fast! Higher Efficiency!
With a blazing speed of up to 30,000 mm/min, this engraving system inherits the proven motion control technology from ACMER Lab. Its robust mechanical structure ensures faster engraving times for artworks, without compromising on stability or ultra-high precision.
