for Creality Sprite Extruder Hotend Replacement for Ender 3 S1 /S1 Pro / Smart Pro

Note: This is the full hotend only, not the upgrade kit for ender 3, do not purchase if you have other printers as the wiring is different.

🏆[Exquisite Shape & Precise Structure]: 54x50x64.3mm small size,288g weight.Exquisite design,perfect combination of extruder and printing hotend make more powerful functions.

🏆[80N Large Torque Design]: The use of gear with 3.5:1 gear ratio which perfectly matches with motor makes extrusion force up to 80N(depending on filaments). More precise control of feeding withdrawal.

🏆[Dual Gear Feeding]: The double-toothed structure does not damage filaments, feeding is more reliable and stable. The tensioner allows you to fine-tune the pressure exerted bt the drive gears onto the filament according to your preferences which helps to print more exquisite models.

🏆[All-metal Hotend Kit]: All-metal Hotend Kit with heating block, titanium throat and cooling block, allows you to print high temperature materials at 300°C.

🏆[Customized Dual Fan]: Simulation of flow field mechanics and dual fan design results in powerful heat dissipation function and more stable model formation.

【All Metal Design】Creality Sprite direct drive extruder pro kit perfectly combine extruder and all metal hotend, enables the Ender 3 S1 series 3D printers a direct extrusion and high temperature printing conditions. This Sprite Extruder Pro only include the extruder itself and doesn't include cable, screws and mount.
• 【80N Large Torque Design】 The use of gear with 3.5:1 gear ratio which perfectly matches with motor makes extrusion force up to 80N (depending on filaments). More precise control of feeding withdrawal.
• 【Dual Gear Feeding- Powerful & Stable】This direct drive extruder adapts double-toothed structure which does not damage filaments, allowing more reliable and stable feeding. The use of gear with 3.5:1 gear ratio which perfectly matches with motor makes extruder force up to 80N. More precise control of feeding withdrawal.
• 【Compatible with】Item not come with control board, mounting bracket, wire. ONLY compatible with Creality Ender-3 S1/Ender-3 S1 Pro/CR-10 Smart Pro 3D Printer.

Key Features:

1: Small Sprite, Huge Power

2: 80N Large Torque Design

3: Dual Gear Feeding

4: All-metal Hotend Kit

5: Customized Dual Fan

6: Adjustable Tension

7: Multi-module Switching

8: Easy to Operate

9: Strong Scalability

10: Compatible with Various Filaments

Product Specifications

Creality Sprite Extruder Pro

Product Size: 54*50*64.3mm

Weight: 288g

Rated voltage: 1.4VDC

Rated current: 0.8A

Drive: Dual gear drive

Reduction ratio: 3.5:1

Maximum extrusion force: 80N(depending on filament)

Withdrawal distance: Max 3mm

Hotend kit: High temperature hotend kit(≤300℃)

Supportable filaments diameter: 1.75±0.05mm

Supportable filaments: PLA,ABS,PA,PC,TPU

Compatible models: Ender-3 S1/CR-10 Smart Pro
